Chrome plated steel throttle pedal features a splined pivot hub which allows easy indexing of arm for use in nearly any vehicle
The arm on the side with the small set screw (1.5 mm) is splined to the central shaft. This allows the installer to tailor the arm/pedal angle to suit their installation
Simple 2 bolt mount to firewall and features 3 holes spaced 1/2″ apart for location of throttle cable attachment
Length of arm from pivot point to top cable mounting hole center is 4.875″, 4.5″ to middle hole and 4.125″ to closest hole
Length of arm from pivot point to center of pedal is 6.63″
